鸟牌Bird|150W油冷式假负载8135
详细信息
8135, 150 Watt, Oil-Cooled Termination is a portable, general purpose 50 ohm coaxial transmission line
termination. It is a self-contained unit requiring no outside power source or additional equipment. This coaxial load
resistor provides an accurate, dependable, and practically non-reflective termination for adjustment, standby, and testing of transmitters under non-radiating conditions.
· Industry standard portable Bench load for general purpose mobile and base station RF
testing up to 4 GHz
· Oil-assisted convection cooling for safe, continuous operation up to 150W full rated power
· Quick Change (QC) connectors to minimize the need for adaptors when making critical
measurements
· Rugged housing with handle and rubber feet for trouble-free operation in the most demanding environments
product specifications:
|
Item No |
8135 |
|
Item Name |
150 Watt, Oil-Cooled Terminations |
|
Power Rating |
150 W continuous |
|
Frequency Range and VSWR |
DC to 1 GHz @ 1.1 max
1 to 2.5 GHz @ 1.2 max
2.5 to 4 GHz @ 1.3 max. |
|
Temperture Range |
-40 to +45 °C |
|
Coolant |
0.1 gal. (380 ml) refined mineral oil |
|
Product Type |
Oil-Cooled |
|
Operating Position |
Horizontal only |
|
Connectors |
N (F) |
|
Finish |
Gray Powder Coat |
|
Dimensions |
9-1/2" x 3-15/16" x 6-11/32" (L x W x H)
241 x 100 x 161 mm |
|
Weight |
6.0 lbs. (2.7 kg) |
8135，150瓦，油冷式终端是一种便携式，通用50欧姆同轴电缆传输线。它是一个自包含的单元，不需要外部电源或额外的设备。同轴负载电阻提供准确，可靠的，几乎不反射终止的调整，待机和非辐射条件下的发射器测试。
· 行业标准的便携式通用的移动台和基站RF测试台负载高达4 GHz
· 辅助油对流散热，安全，连续工作可达150W的额定功率
· 快速变化（QC）的连接器，适配器需要时，*大限度地减少关键测量
· 在*苛刻的环境下坚固耐用的外壳，手柄和橡胶脚垫，无故障运行
产品规格：
|
产品编号 |
8135 |
|
产品名称 |
150 W，油冷式终端 |
|
额定功率 |
150 W continuous |
|
频率范围和VSWR |
DC to 1 GHz @ 1.1 max
1 to 2.5 GHz @ 1.2 max
2.5 to 4 GHz @ 1.3 max. |
|
温辐射范围 |
-40 to +45 °C -40到+45°C |
|
冷却液 |
精制矿物油（380毫升） |
|
产品类型 |
Oil-Cooled油冷式 |
|
操作位置 |
Horizontal only仅水平 |
|
连接器 |
N (F) |
|
外觀 |
灰色粉末涂层 |
|
尺寸 |
9-1/2" x 3-15/16" x 6-11/32" (L x W x H)
241 x 100 x 161 mm |
|
重量 |
（2.7公斤） |
