产品编号 |
5016 |
|
Item Name 产品名称 |
25 mW - 25 W Avg, 60 W Peak Wideband Power Sensor
25 MW - 25 W 60 W平均，峰值宽带功率传感器 |
|
Frequency Range 频率范围 |
350 MHz - 4.0 GHz |
|
Power Range 功率范围 |
25 mW - 25 Watts Avg.
25毫瓦 - 25瓦Avg。
60 Watts Peak 60瓦峰值 |
|
Insertion VSWR 插入VSWR |
<1.05 from 0.35 to 2.5 GHz
<1.10 from 2.5 to 4 GHz |
|
Insertion Loss 插入损耗 |
<0.05 dB from 0.35 to 1.0 GHz <0.1 dB from 1 to 4 GHz <0.1 dB的从1到4 GHz |
|
Directivity 方向性 |
30 dB up to 3.0 GHz, 28 dB from 3.0 to 4.0 GHz 30分贝28 dB，从3.0到4.0 GHz到3.0 GHz， |
Average Power
平均功率 |
Average Forward Power Range: 25 mW - 25 Watts Avg, 60 Watts Peak
平均正向功率范围：25毫瓦- 25瓦，60瓦峰值平均
*Accuracy, Average Forward Power: ± 4% of reading, + 0.008 W
*准确度，平均正向功率读数的±4％，+ 0.008 W
Minimum Forward Power for Reflected Measurement: 1.0 W
*低反射的测量正向功率：1.0 W
Return Loss: 0.0 to 23 dB
回波损耗：0.0元至23分贝
VSWR: 1.15 to 99.9
驻波比：1.15〜99.9
Rho: 0.07 to 1.0 rho |
Burst Average Power
突发平均功率 |
Burst Average Forward Power Range: .7 W - 25 Watts Avg
突发平均正向功率范围：0.7 W - 25瓦Avg
Burst Width: 1 μs to 50 ms
脉冲宽度：1μs至50毫秒
Repetition Rate: 200 Hz, Min
重复频率：200赫兹，*小
Duty Cycle (D): .001 to 1.0
占空比（D）：0.001至1.0
*Accuracy, Burst Average Power: ± 6% of reading, + 0.008/D Watts
*精度，突发平均功率：读数的±6％，+ 0.008 / D瓦 |
Peak Envelope Power Range
峰值包络功率范围 |
0.7 - 60 W |
Accuracy---Peak Envelope Power
精度---峰值包络功率 |
burst width > 200 μs: ± 7% of reading, + 0.05 W
脉冲宽度200微秒：±7％读数+ 0.05 W
1 μs < burst width < 200 μs: ± 10% of reading, + 0.10 W
1μs的脉冲宽度<200微秒：读数的±10％，+ 0.10 W
0.5 μs < burst width < 1 μs: ± 15% of reading, + 0.10 W
0.5微秒脉冲宽度<1微秒：读数的±15％，+ 0.10 W
burst width < 0.5 μs: ± 20% of reading, + 0.10 W
脉冲宽度<0.5微秒：读数的±20％，+ 0.10 W |
|
Crest Factor 波峰因数 |
Crest Factor Measurement Range: 25mW-25 Watts
波峰因数测量范围：25毫瓦- 25瓦
*Accuracy, Crest Factor: Linear Sum of Peak and Average Power Accuracies
*精确度，波峰因数：线性和峰值功率和平均功率的准确度 |
Complementary Cumulative
Distribution Function
互补累积分布函数 |
CCDF Measurement Range: 0.1 to 100%
CCDF测量范围：0.1〜100％
Threshold Measurement Range: 0.7 - 25 W
阈值测量范围：0.7 - 25 W
Measurement Uncertainty: ± 0.2%
测量不确定度：±0.2％
*Level Set Accuracy: As Peak Envelope Power Accuracy + 2.0%
*等级设定精度：由于峰值包络功率精度：±2.0％ |
|
Connectors 连接器 |
N (F) N（F） |
Power Supply
电源供应器 |
USB Port: less than one low-power USB load
USB接口：不到一个低功耗的USB负载
DC Input Connector: 7-18 VDC at less than 0.1A
直流电源输入接口：7-18 VDC小于0.1A |
|
Impedance Ω 阻抗（Ω） |
50 (nominal) 50（额定的） |
|
Interfaces 接口 |
DPM Interface: DB9 proprietary interface
DPM接口：DB9的专用接口
PC Interface (1): RS-232, 9600 Baud, no parity, 8 data bits, 1 stop bit, DB9
（1）PC接口：RS-232，9600波特，无奇偶校验，8个数据位，1位停止位，DB9
PC Interface (2): USB 1.1 Type B, compliant interface
（2）PC接口：USB 1.1 B型，兼容的接口， |
|
Weight 重量 |
1.2 lbs., max. |
|
Dimensions H x W x D 尺寸（高x宽x深） |
4.8" x 4.6" x 1.3" (122 x 117 x 33 mm) |
Data Logging
数据记录 |
Requires 5000-XT or VPM2
需要5000-XT或VPM2的的 |
Operating Temperature
工作温度 |
-10 to +50 °C (+14 to +122 °F) |
Storage Temperature
储存温度 |
-40 to +80 °C (-40 to +176 °F) |
Mechanical Shock and Vibration
机械冲击和振动 |
IAW MIL-PRF-2880F Class 3 |
