Description |
SH-36 Series, SignalHawk - Spectrum Analyzer |
|
Frequency Range |
100 kHz to 3.6 GHz |
|
Frequency Resolution |
1 Hz |
|
Frequency Uncertainty |
± 1 ppm |
|
Reference Aging |
± 1 ppm / year |
|
Temperature Drift |
± 1 ppm / °C |
|
Data Points |
705 displayed |
|
Spectral Purity |
-85 dBc @ 30 kHz |
|
Sweep Time |
2.2 s, full span; 1 ms, zero span |
|
Resolution Bandwidth |
100 Hz - 1 MHz RBW |
|
Video Bandwidth |
10 Hz - 300 kHz VBW |
|
Amplitude Accuracy |
± 1.0 dB typ, ± 1.5 dB max |
|
Dynamic Range |
66 dB, intermod-free |
|
Noise Floor |
-135 dBm DANL |
|
Attenuator |
0, 10, 20, or 30 dB; internal |
|
Pre-Amplifier |
+24 dB gain, internal |
|
Single Button Measurement |
Occ BW, Channel Power, ACPR, Field Strength, AM/FM Demod, C/I |
|
RF Input, N(F) |
+20 dBm (100 mW) max |
|
Display |
8.4”, TFT, 800 x 600 pixels |
|
Battery |
5.5 hour, Field Replaceable |
|
Drop Tested |
1 meter per EN 61010-1 |
|
Transit Drop Test |
10 drops per MIL-PRF-28800F |
|
Explosive Atmosphere |
Per MIL-PRF-28800F 4.5.6.3 |
|
Standards Compliance |
CE |
|
Connectivity |
PC; USB drive and accessories |
|
Saved Trace Storage |
300 internal; 90,000 USB drive |
|
Win CE Viewers |
Word, Excel, PPT, PDF, Image |
|
Dimensions |
11.5” x 10.5” x 3.8” |
|
Weight |
7.8 lbs (3.5 kg) |
|
Standard Accessories |
Soft Carry Case, Operators Manual, Quick Start Instructions, 10 ft. USB Cable - USB A (M) to USB B (M), AC Adapter/Charger, Car Adapter/Charger, Internal Li-Ion Battery (Field Replaceable), PC Tool Software and Manual CD's, USB Flash Drive - Win CE compatible |
|
Power Meter Option |
5010B, 5010T, 5011, 5011-EF, 5012A, 5016 and 5017 External Power Sensors, Optional |
