500 Watt, Oil-Cooled Terminations
The 8201 TERMALINE® Load Resistor is a portable, self-contained general purpose 50 ohm coaxial transmission line termination requiring no outside power source or
additional equipment. It provides accurate, dependable, and practically nonreflective termination for testing and
adjusting transmitters under nonradiating conditions. The load consists essentially of a cylindrical film type
resistor immersed in a dielectric coolant. The resistor, individually selected for its accuracy, is enclosed in a
special tapered housing which provides a linear reduction in surge impedance directly proportional to the distance
along the resistor. This produces the uniform, practically reflectionless line termination from dc to 2.5 GHz.
Rugged portable Bench load for medium power base station RF testing up to 2.5 GHz
· Oil-assisted convection cooling for safe, continuous operation up to 500W full rated power
· Quick Change (QC) connectors to minimize the need for adaptors when making critical measurements
· Low-profile housing with handle and rubber feet for trouble-free operation in the most demanding environments
Power Rating (Watts) |
500 continuous |
Frequency Range and VSWR |
DC to 1 GHz at 1.1 max,
1 GHz to 2.5 GHz at 1.25 max |
Coolant |
0.9 gal. (3.42 liters) refined mineral oil |
Product Type |
Oil-Cooled |
Ambient Temp Range [°C (°F)] |
-40°C to +45°C |
Operating Position |
Horizontal only |
Connector(s) |
QC Type (N-Type (F) supplied) |
Finish |
Gray Powder Coat |
Nominal Size [inches (mm)] |
16 13/16" L x 8 1/2" H x 5 15/16" W, (427 mm x 216 mm x 151 mm) |
Weight [lbs (kg)] |
21 lbs. (9.5 kg) |
