300 Watt, Convection-Cooled Dry Terminations
Bird's RF terminations are world renowned for their high-quailty, robust construction and conservative power ratings. The use of non-magnetic materials and plating provide safety when used in high magnetic fields such as MRI. No fluids or maintenance required.
Convection-Cooled
· High Quality construction
· Rugged Reliability provides years of trouble free use
· Compact size, easily transportable benchtop design
Power Rating (Watts) |
300 |
|
Frequency Range and VSWR |
DC to 1 GHz at 1.10:1 max, 1 GHz to 2.4 GHz at 1.25:1 max. |
|
Coolant |
Dry (Convection-Cooled) |
|
Ambient Temp Range [°C (°F)] |
-40°C to +40°C |
|
Operating Position |
Vertical |
|
Connector(s) |
N-Type, BNC, TNC, 7/16 DIN |
|
Finish |
Black Anodized, Silver or Tri-Alloy Plated Connectors |
|
Nominal Size [inches (mm)] |
(with N-type connector): 10.9" H x 5.4" W x 16.8" D, (276.9 mm x 137.2 mm x 172.8 mm) |
|
Weight [lbs (kg)] |
11.5 lbs. (5.23 kg) |
