150 Watt, Convection-Cooled Dry Terminations
Bird's RF terminations are world renowned for their high-quailty, robust construction and conservative power ratings. The use of non-magnetic materials and plating provide safety when used in high magnetic fields such as MRI.
Avaliable with N or BNC Connectors
· Convection-Cooled
· Rugged Reliability provides years of trouble free use
· Compact size, easily transportable benchtop design
Power Rating (Watts) |
150 |
|
Frequency Range and VSWR |
DC to 1 GHz at 1.10:1 max,
1 GHz to 2.4 GHz at 1.25:1 max |
|
Product Type |
Dry (Convection-Cooled |
|
Ambient Temp Range [°C (°F)] |
-40°C to +40°C |
|
Operating Position |
Vertical |
|
Connector(s) |
N-Type, BNC, TNC, 7/16 DIN |
|
Finish |
Black Anodized, Silver or Tri-Alloy Plated Connectors |
|
Nominal Size [inches (mm)] |
10.9" H x 2.6" W x 6.8" D (276 x 66 x 173mm) |
|
Weight [lbs (kg)] |
6.0 lbs. (2.73 kg) |
