100 Watt, Convection-Cooled Dry Terminations
Termaline® RF Coaxial Terminations
Bird's RF terminations are world renowned for their high-quailty, robust construction and conservative power ratings. The use of non-magnetic materials and plating provide safety when used in high magnetic fields such as MRI.
Wide variety of connectors
· Rugged Reliability provides years of trouble free use
· Compact size, easily transportable benchtop design
· High Quality Construction
Power Rating (Watts) |
100 |
|
Frequency Range and VSWR |
DC to 1 GHz at 1.10:1 max, 1 GHz to 2.4 GHz at 1.25:1 max. |
|
Operating Temperature (°C) |
-40°C to +40°C |
|
Product Type |
Dry (Convection-Cooled) |
|
Operating Position |
Vertical |
|
Connector(s) |
N-Type, BNC, 7/16 DIN |
|
Finish |
Black Anodized fins. Silver or Tri-Alloy Plated connector |
|
Nominal Size [inches (mm)] |
(with N-type connector): 6.4" L x 2.6" W x 7.0" H, (162.6 mm x 66.1 mm x 172.8 mm) |
|
Weight [lbs (kg)] |
3.6 lbs. (1.64 kg) |
