| | 品牌：鸟牌Bird | | 型号：75-T-FN假负载 | | 加工定制：否 | |
欢迎索取详细技术图纸！请点击！
75 Watt, Convection-Cooled Dry Terminations
Termaline® RF Coaxial Terminations
Bird's RF terminations are world renowned for their high-quailty, robust construction and conservative power ratings. The use of non-magnetic materials and plating provide safety when used in high magnetic fields such as MRI. For
Aluminum Nitride (BeO free) see model 75-NT-MN
Wide variety of connectors
· Rugged Reliability provides years of trouble free use
· Compact size, easily transportable
· Optionally available with Aluminum Nitride ceramic
Power Rating (Watts) |
75 |
|
Frequency Range and VSWR |
DC to 1 GHz at 1.10:1 max,
1 GHz to 4 GHz at 1.25:1 max. |
|
Product Type |
Dry (Convection-Cooled) |
|
Ambient Temp Range [°C (°F)] |
-40°C to +40°C |
|
Operating Position |
Any |
|
Connector(s) |
N-Type, BNC, TNC, SMA, 7/16 DIN |
|
Finish |
Black Anodized,
Silver or Tri-Alloy Plated Connectors |
|
Nominal Size [inches (mm)] |
(with N-type connector):6.7" L x 2.3 Dia., (170.2 mm x 58.5 mm) |
|
Weight [lbs (kg)] |
1.32 lbs. (0.6 kg) |
