10 Watt, Convection-Cooled Dry Terminations
Termaline® RF Coaxial Terminations
Bird's RF terminations are world renowned for their high-quailty, robust construction and conservative power ratings. The use of non-magnetic materials and plating provide safety when used in high magnetic fields such as MRI. For Aluminum Nitride (BeO free) see model 10-NT.
Wide variety of connectors
· Rugged Reliability provides years of trouble free use
· Compact size, easily transportable
· Optionally available with Aluminum Nitride ceramic
Power Rating (Watts) |
10 |
|
Frequency Range and VSWR |
DC - 1 GHz @ 1.10:1 max.
1 GHz - 4 GHz @ 1.25:1 max. |
|
Product Type |
Dry (Convection-Cooled) |
|
Ambient Temp Range [°C (°F)] |
-40°C to +40°C |
|
Operating Position |
Any |
|
Connector(s) |
N-Type, BNC, TNC, SMA, 7/16 DIN |
|
Finish |
Black Anodized, Silver or Tri-Alloy Plated Connectors |
|
Nominal Size [inches (mm)] |
2" L x 2.3" Dia. with N connector
50.8 x 58.5 mm |
|
Weight [oz. (g)] |
5.1 oz. (146 g) |
