5 Watt, Convection-Cooled Dry Terminations
Termaline® Series RF Coaxial Terminations
Bird designs custom and standard solutions for RF APPLICATIONS! Bird manufactures a broad line of power
terminations from .5 Watt to over 80 kW. Our resistive product portfolio includes air, water cooled, oil dielectric,
convection cooled, and conduction cooled loads.
Power Rating (Watts) |
5 |
|
Frequency Range and VSWR |
DC - 1 GHz @ 1.10:1 max.
1 GHz - 6 GHz @ 1.25:1 max. (N type)
1 GHz to 4 GHz @ 1.25:1 max. (BNC and TNC) |
|
Product Type |
Dry (Convection-Cooled) |
|
Ambient Temp Range [°C (°F)] |
-40°C to +40°C |
|
Operating Position |
Any |
|
Connector(s) |
N-Type, BNC, TNC |
|
Finish |
Silver or Tri-alloy plated |
|
Nominal Size [inches (mm)] |
1.6" L x 0.8" Dia., with N(M) connector
(40.7 mm x 20.4 mm) |
|
Weight [oz. (g)] |
1.9 oz. (55 g) |
