50 Watt, Convection-Cooled Dry Terminations
Termaline® RF Coaxial Terminations
Bird's RF terminations are world renowned for their high-quailty, robust construction and conservative power ratings. The use of non-magnetic materials and plating provide safety when used in high magnetic fields such as MRI.
For Aluminum Nitride (BeO free) See 50-NT-MN
Wide variety of connectors
· Compact size, easily transportable. Rugged Reliability provides years of trouble free use
· Optionally available as a Calibrated Mismatch Load See 50-T-MN-3R00
· Optionally available with Aluminum Nitride ceramic
Power Rating (Watts) |
50 |
|
Frequency Range and VSWR |
DC to 1 GHz at 1.10:1 max, 1 GHz to 4 GHz at 1.25:1 max. |
|
Product Type |
Dry (Convection-Cooled) |
|
Ambient Temp Range [°C (°F)] |
-40°C to +40°C |
|
Operating Position |
Any |
|
Connector(s) |
N-Type, BNC, TNC, SMA, 7/16 DIN |
|
Finish |
Black Anodized, Silver or Tri-Alloy Plated Connectors |
|
Nominal Size [inches (mm)] |
(with N-type connector): 4.7" L x 2.3" Dia., (119.4 mm x 58.50 mm) |
|
Weight [lbs (kg)] |
1.13 lbs. (0.52 kg) |
